Mini-Emulsion and UG Units

Advanz Mini-Emulsion Units are used for pre-split, post-split, and secondary blasting applications. These units are highly mobile and cost effective when compared to an MMU when requiring small volumes per blast hole further advantages includes the fact it’s able to fit on a small vehicle with a low carrying capacity.

• Pumps are pneumatic or hydraulic driven.
• Gasser Tanks – 10 litres
• Emulsion Tanks 1-2 tons
• PLC or Manual controlled

Advanz Mining offers Hydraulic driven UG MCU's  with the following specifications:

Specifications

• 1-to-2.5-ton units. Larger units are available on request
• Pumping Rates 30-40kg/min
• World Class Pumps
• Max hose length 30 m
• Hydraulic Oil req. 60L/min @160 bar
• Gasser tank - 30 - 90 L
• Water Tank - 30-90 L
• Danfoss PLC
• Record-able Parameters
• Gassing ratio form 0.4% to 3%
• Multiple Safety and Product trip features

*** See Downloads for Product Brochure and Specifications
